Cnc Laser Cutting Machine / Medium Power Co2 Laser Engraving Machine 80w 100w 150w

Name: Cnc Laser Cutting Machine Medium Power Co2 Laser Engraving Machine 80w 100w 150w
Brand: Promega
Price: 2000 USD

Buy cheap Cnc Laser Cutting Machine / Medium Power Co2 Laser Engraving Machine 80w 100w 150w product

Brand Name : Promega

Model Number : Pro-LCM-80/100/150

Certification : CE

Place of Origin : China

MOQ : one set

Price : USD 2000 ~ 3500 per set

Payment Terms : L/C, T/T

Supply Ability : 10 sets per week

Delivery Time : 3 ~ 5 working days

Packaging Details : In wood case

Condition : New

Laser Power : 80~150 watts

Working area : 900mmx600mm

Moving Speed : 0~50mm/s

Package size : 1535x1350x1250

Gross weight : 360kg

Contact Now

Medium Power CO2 Laser Engraving Machine Cnc Laser Cutting Machine 80W 100W 150W

Applicable Material

This machine can be usd to cut cloth,leather,wool,fur,acrylic,plexiglass,wooden board,plastic,resin,rubber,bamboo product,resin and other non-metal materials. According to different needs, customers can choose 80 watt, 100 watt and 150watt machine.

Adavantage

The machine is suitable for garment,leather,package and printing,advertisement decoration,building upholster,art gift,computer embroidery,paper product,acrylic board of plastic,middle density board etc.non-metal sheet precision cutting and other industries.

Cnc Laser Cutting Machine / Medium Power Co2 Laser Engraving Machine 80w 100w 150w

Technical Parameters

Laser Power	50-150W(optional)
Laser Type	hermetic Co2 glass tube
Power Supply	AC220±10% 50HZ/AC 110±10% 60HZ
Working Area	900mm×600mm
Max Moving Speed	0---50mm/s
Worktable	honeycomb worktable/up&down worktable/aluminium knife(optional)
Locating Precision	＜0.01mm
Min Shaping Character	character:3×3mm,letter:2×2mm
Operating Temperature	5℃---35℃
Resolution Ratio	≤4500dpi
Control Configuration	DSP
DataTransfer Interface	USB(offline)
Svstem Environment	WINDOWS 2000/WINDOWS XP/Vista/win7
Cooling Way	water cooling and protection system
Graphic Format Supported	the files which CoreDraw,photoshop,AutoCAD can identify(BMP,GIF,JPEG,PCX,TGA,TIFF,PLT,CDR,DMG,DXF,PAT,CDT,CLK,DEX, CSL,CMX,AI,WPG,WMF,EMF,CGM,SVG,SVGZ,PCT,FMV,GEM,CMX)
Compatible software	CorelDraw,AutoCAD
Cutting Thickness	0---20mm(depends on different materials)
Color Separation	separation of cutting up to 256 colors
Sloping Engraving	yes,slope can be designed discretionarily
Cuts off the Water Supply the Protection	yes
Machine Dimension	153512001025 mm
Package Dimension	170013501250 mm
New Weight	280kg
Gross Weight	360kg
Optional Parts	high-grade cooling system/imported focus lens/dobble-head/cylinder rotary attachment/irregular rotary attachment
